Specification: Capacity: 25 MW (2 units of 4.5 MW and 2 units of 8 MW) Type of power house: Surface Average annual power generation: 3700 GWh Main equipment: Turbine: Vertical Francis, 2 units 33 rpm, 2 units 500 rpm Generator: Synchronous type, 2 units 7.7 MW, 2 units 5.1 MW Butterfly valve: 2 units 2000 [...]
Read more
Specification: Capacity: 220 MW (2 Units of 110 MW) Type of power house: Surface Average annual power generation: 1000 GWh Main equipment: Turbine: Vertical Kaplan, 72 rpm Generator: Synchronous type, 13.8 KV Governor: Digital type governors, 63 bar Busduct: Air busducts, 13.8 KA Transformer: Three phase step up Transformers, 125 MVA Switchgear: 220 KV Crane: [...]
Read more
General specification: Turbine Type: Cyclone SGT – 400 Siemens Design Pressure: 1450 psia Maximum Compressor Discharge Pressure: 1311 psia ISO Rating: 13.4 MW Synchronous Speed: 9500 rpm Maximum Station Discharge: 36.2 MMSCMD Pipelines: 8 Km Role of Nardis Energy Projects Co. Management contracting
Read more
Ilam petrochemical complex consists of olefin, HDPE and utility units. The total electrical power demand of this complex is around 4x30.22 MW (ISO condition) or about 4x21 MW (at worst case 42 oC , 60% RH) which is generated by minimum 4 (+1 future) gas turbine generators (GTGs). The MP steam (MPS) demand is 80 [...]
Read more
Specification: Capacity: 480 MW (3 Units of 160 MW) Type of power house: Surface Average annual power generation: 843.8 GWh Main equipment: Turbine: Vertical Francis, 187.5 rpm, 470 tons each Generator: Synchronous type, 13.8 KV Butterfly valve: 5 m inner outlet diameter Governor: Digital type governors, 64 bar Generator busduct: IPB, 9000 A, 13.8 KV [...]
Read more
Capacity: 47 MW (2 Units of 23.5 MW) Type of power house: Underground Average annual power generation: 152.4 GWh Main equipment: Turbine: Vertical Francis, 750 rpm Generator: Synchronous type, 11 KV Inlet valve: Spherical, 1 m inner outlet diameter Governor: Digital type with digital backup governors, 100 bar Transformer: Three phase step up transformers, 27 [...]
Read more
Specification: Capacity: 1,000 MW (4 Units of 250 MW) Type of power house: Underground Average annual power generation: 152.3 GWh Main equipment: Turbine: Vertical Francis pump-turbine with capacity of 260 MW in turbine situation and 235 MW in pump situation, 700 tons each Generator/ Motor: Motors with capacity of 300 MVA in generator situation and [...]
Read more
Specification: Spillway Structures: 540 tons Dam Equipment: Diversion gate equipment Spillway stoplogs Bottom outlet Irrigation equipment Intake equipment Role of Farab Equipment Manufacturing Co. Design, Material Supply and Manufacturing Management of: Spillway radial gates Spillway Stop log gate Spillway lifting beam Bottom outlet maintenance gate Bottom outlet maintenance emergency gate and casing Bottom outlet steel [...]
